MODEL SHC12 SHC16 SHC20 SHC30
WEIGHING MODE Single range Single range Single range Single range
CAPACITY kg 12 16 20 30
READABILITY g 0.1 0.1 0.1 0.1
TARE RANGE kg 0-12 0-16 0-20 0-30
REPEATABILITY ( std dev) g 0.2 0.2 0.2 0.2
LINEARITY g ± 0.2 ± 0.2 ± 0.2 ± 0.3
STABILIZATION TIME s ~ 3 ~ 3 ~ 3 ~ 3
EXT. CALIBRATION WEIGHT kg 4kg 4kg 10kg 10kg
WEIGHT 21.4lbs/ 9.7kg 21.4lbs/ 9.7kg 21.4lbs/ 9.7kg 24.5lbs/ 11.1kg
UNITS OF WEIGHT lbs, g, ct, oz, dwt, ozt, grains, HK taels, Singapore taels, ROC taels, momme
DATA INTERFACE RS232 bidirectional. Selectable baud rates are 1200, 2400, 4800, and 9600
PAN SIZE Rectangular 12.5 " x 8.5 " / 318mm x 216mm
SCALE HOUSING ( WxDxH) 12.8 " x 12.5 " x 4 " / 324mm x 318mm x 101mm
